Description
| Feature | Specification |
|---|---|
| Length | 3.87″ (short) / 5.75″ (full) |
| Weight | 5.1 oz (short) / 8 oz (full) |
| Material | 17-4 Stainless Steel |
| Finish | Black Nitride |
| Thread Mount | 1/2×28 Direct Thread |
| Caliber Compatibility | .22 LR, .22 Mag, 5.7x28mm |
| Full Auto Rated | Yes – rated for full-auto fire in .22 LR, .22 Mag (no barrel restriction), and 5.7x28mm (minimum 5″ barrel) |
| Semi-Auto Barrel Restrictions | No barrel length restrictions for .22 LR, .22 Mag, or 5.7x28mm |
| Serviceable | Yes |
| Warranty | Faxon Lifetime Guarantee |
| Max Body Diameter | 1.070″ |
| Minimum Extension Diameter | 1.00″ |
| Wrench Flats | 1.000″ and 0.875″ |
In the Box
| Item | Description |
|---|---|
| Suppressor | Faxon Twenty-Toucan® .22cal Modular Suppressor |
| Extension Tube | Modular tube for full-length configuration |
| End Cap | Threaded end cap for secure closure |
| Challenge Coin | Rifled .50 cal barrel slice coin for end cap removal |
| 3D Printable Tool | Download alternate end cap removal tool file |
Performance Results (dB Reduction vs. Bare Muzzle)
| Platform | Configuration | Reduction vs Bare Muzzle |
|---|---|---|
| 16″ Semi-Auto Rifle
Standard Velocity |
Full Configuration | 28.8 dB |
| Short – Perforated | 15.8 dB | |
| Short – Non-Perforated | 16.2 dB | |
| 18″ Bolt Action
CCI Quiet |
Full Configuration | 26.6 dB |
| Short – Perforated | 12.6 dB | |
| Short – Non-Perforated | 17.4 dB | |
| 4″ Semi-Auto Pistol
Standard Velocity |
Full Configuration | 28.2 dB |
| Short – Perforated | 19.5 dB | |
| Short – Non-Perforated | 16.8 dB |
Real-World Tuning Tips
- In short configuration, you can choose to use either perforated or non-perforated baffles depending on your goals.
- For longer configurations, experiment with placing perforated baffles closer to the breech to manage gas and backpressure, or toward the muzzle to reduce flash.
- Try alternating baffle types to find your preferred balance of tone, flash reduction, and gas dispersion.
Order your Faxon Twenty-Toucan® and enjoy the most tunable, durable, and fun .22 suppressor on the market—backed by Faxon’s Lifetime Guarantee.
